Flex Grid Optics

 PRODUCT SPECIFICATION

MAIN FEATURES

• Support for 10GBASE Ethernet
• Provides flexibility of interface choice
• Hot-swappable input/output allows for connection into X2 port of any Cisco switch or router to provide network link
• Full Support for Cisco Quality Identification (ID) feature, enabling a Cisco switch or router to identify whether the module is certified and tested by Cisco, 100% Cisco compatible
• Optical interoperability with 10GBASE Xenpak, 10GBASE XFP and 10GBASE SFP+ modules on the same link system
• Supports link lengths of upto 80 km on SFP in ideal conditions


TECHNICAL SPECIFICATIONS

Platform support:

Smart Fibroptics X2 modules are 100% compatible and supported on Cisco switches and routers. For more details, refer to the document Cisco Xenpak/X2 Compatibilty Matrix.

Connectors & Cabling:

Dual SC/PC connector (-SR, -LR, -LRM, -LX4, -ER, -ZR); InfiniBand 4x Connector (-CX4); RJ-45 connector (-T).

Dimensions:

• Dimensions (D x W x H): 91mm x 36mm x 13.46mm weighing typocally under 300 grams
• Envoirnmental Conditions & Power Requirements
• The operating temperature range is between 0 and 70ºC (32 to 158ºF); storage temperature range is -40 to 85ºC (-40 to 185ºF)
• The maximum power consumption per Cisco X2 module is 4W

Warranty:

• Standard 1 year warranty
